Automatic Bridge Saw GBHW-1200

  • Automatic Bridge Saw GBHW-1200 Manufacturers, Automatic Bridge Saw GBHW-1200 Factory, Supply Automatic Bridge Saw GBHW-1200
Automatic Bridge Saw GBHW-1200
  • Great Base
  • CHINA
  • 30 days
  • 20sets per month

GREAT BASE (GB machine) GBHW-1200 Auto Bridge Stone Saw Machine is designed and produced by our GREAT BASE factory, China stone machine manufacturer, GBHW-600/800 is idea machine for granite marble stone cutting , floor slab cutting, paving stone cutting, with 90degree rotating worktable, thick stone or kerbstone cutting machine, tombstone cutting machine. GREAT BASE (GB machine) worked in stone processing machine industry nearly 20 years, our GREAT BASE (GB machine) different types stone cutting and polishing machine working in more than 60 countries and we have several partners agents in different countries or area. We can provide professional solution and good service for all of our abroad clients about stone cutting, polishing, edge cutting, special shape processing, splitting, quarrying.

The most wide usage and sales Auto Bridge Saw Machine.

Introduction : Great Base (GB machine) GBHW-1200 Automatic Bridge Saw Edge Cutting Machine China, adopts PLC control to set program for granite / marble slab cutting, cutting paving stone, cutting granite marble floor tiles slab, cutting road side stone, paving stone, tombstone, monuments stone. Two inverters for X, Y axis movements speed control, four pieces column and double cylinder up/down to get higher cutting capacity. Imported encoder for calculating the cutting thickness , with high precision .Heavy duty casting iron crossbeam, It is very important machine besides our GBQQJ series Granite Multi Blade Cutting Machine, GBLXM series stone polishing machine, GBXJ Special shape profile saw. GBYH engraving machine. Very good for thick slab cutting such as paving granite factory, kerbstone cutting factory and other granite cutting company.



Specification

GBHW-1200

Main motor

kw

22

Feeding Motor

kw

2.2

Slicing Motor

kw

1.5

Max.cutting size

mm

3000x2000x450

Cutter head up/down stroke

mm

750

Table rotating angle

90degree

Total weight

kgs

About 5500

Dimension

mm

6000x4700x3400


GBHW-1200 bridge cutting machine for sale, is a highly automatic machine well built to perform various tasks in marble and granite processing. It is ideal for cutting building stone into paving floor slab, wall windows slab, kerbstone, granite and marble slab, tombstone and etc.



GBHW-1200 marble bridge cutting machine, main beam is made of high quality cast iron with high rigidity. It's good to adsorb the great pressure conveyed from machine blade generated during granite and marble stone cutting process. The heavy duty and strong cast iron cross-beam has been granted thick walls to prevent shape deformation in the long years to come.



Great Base (GB machine) GBHW-1200 Automatic Bridge Saw Tombstone Cutting Machine can install Max.D.1200mm to cut 450mm depth, Two V-shaped tracks have been machined on the top of the bridge saw machine cross-beam with small clearance to guide blade X-axis movement. These tracks are an insurance of the blade cutting in straight line. They are oil-bathed and covered with organ shield to prevent dust and water for well performance and long time use.



GBHW-1200, China cheap bridge saw from China, produced by GB machine factory. The cross-beam is rested on and moveable along two rails which are firmly installed on concrete foundation(client can buy the machine with our standard concrete wall or steel structure welded wall base) to ensure the china bridge cutting machine saw vibration free. The cross-beam rails are actually a gear and rack way system to allow for the cross-beam smooth movement and precise positioning. Imported encoder to calculate the cutting precision can be under 0.5mm



Great Base (GB machine) GBHW-1200 Automatic Bridge Saw Machine ,In the right end of the cross-beam are electric cabinet and control panel with LCD display. Cutting parameters can be set into the machine by control panel and then the bridge edge cutting saw machine makes automatic cutting according its PLC program setting. Two frequency converters are also used to enable the granite and marble edge cutting machine fit for cutting stones of different hardness and using blade with different diameters. If clients need, we also can add inverter for main motor so change the RPM of saw blade to suitable for different size circle saw blade such as from D.800 to D.1200 cutting. Or suitable for different hardness granite marble stone cutting.



Great Base (GB machine) GBHW-1200 Automatic Bridge Saw Machine , The bridge saw machine table is hydraulic powered in a dimension 3000mm long x 2000mm wide, heavy duty H shape steel weld. Rotate 90 degree to make a slab all four sides cutting very easy (It can tilt 85 degree in GBHW-400/600/800 bridge saw machine, countertop bridge saw, or GBHW-500L/600L mono block bridge saw, GBHW 3axis bridge saw, GBHW 5 axis bridge saw, CNC bridge saw machine )



This granite cutting machine manufactured by GB machine factory, Blade lifting

/lowering movements in the GBHW series bridge saw machine is powered by two pneumatic cylinders and guided by four chrome-plated steel up and down columns. Flexible limiting blocks are presented on cross-beam and blade holder for easy adjustment of blade moving range, vertical or horizontal, according to stone cutting purpose.



Great Base (GB machine) GBHW-1200 Automatic granite marble tiles cutting Machine, The metal body of the bridge saw machine is inner lined with putty and well painted on the surface to protect from rusting. All thick electric cables are held by drag chain to ensure safety and long service life. With detailed electric diagram drawings so client can check the electric wiring and installation easy.


Advantage of GB machine

1) GREAT BASE products 90% is for export, we are China stone cutting machine manufacturer for sale, Great Base (GB machine) GBHW-1200 granite and marble bridge type edge cutting machine is the most common and widely used in granite / marble thick slab such as kerbstone, paving stone, tombstone cutting , The structure of this machine is heavy duty, and produced for many years, with stable performance and high precision cutting, very good for thick indian black granite, indian black galaxy granite, tan brown granite, russian Gabro granite and other granite slab marble slab cutting. GBHW-1200 bridge cutting machine price cheap from China and clients can choose machine


stone machine


bridge edge cutting machine


bridge cutting machine


stone machine


2) Great Base (GB machine) GBHW-1200 granite and marble bridge type edge cutting machine ,adopting advanced world famous brand components in electric parts .

Main PLC : PANASONIC, Japan

Inverter (two pcs): JAROL, CHINA

bridge edge cutting machine


bridge cutting machine


Or we can adopt the more higher cost famous brand electric parts according to clients’ requirements.

3) Great Base (GB machine) GBHW-600/800 bridge saw machine , we have sold many places, you can see the working performance maybe near to you, just let send us email, i will suggest to you. Widely sold in Russia, Ukraine, Bulgaria, Uzbekistan, India, Unite state, Canada,George, Saudi Arabia, Egypt, South Africa, Kuwait and other places.

4) We are professional stone processing machine manufacturer located in XIAMEN, CHINA, nearly 20 years in stone processing machine industry, our machines are working in more than 60 countries, hot sale bridge saw GBHW series, best polishing machine GBLXM series, Multi disc stone cutting machine GBQQJ series, we can supply different series machines for small,middle, and big stone processing factory, including big stone cutting machine, block cutting machine, granite stone cutting machine, auto stone polishing machine, floor polishing machine, bridge cutting machine from China, marble bridge saw, granite bridge saw also can suggest clients the most suitable for him. we know what kind service need for our abroad clients. Professional service and timely after service is very important for abroad clients. Great Base (GB machine) GBHW-600/800 granite and marble bridge type edge cutting machine is the most common and widely use hot sale bridge saw machine , very suitable for granite marble tiles edge cutting.



More detailed machine parts photos:







Main usage and data:

Great Base (GB machine) GBHW-1200 granite and marble bridge saw machine is supplied by our GREAT BASE factory China, GBHW-1200 can do paving stone cutting, granite floor slab cutting, granite kerbstone , road side stone cutting and processing, tombstone cutting. It also can work with GBTS-1200/1600 Multi blade Stone Cutting Machine, GBQS-2500/2700/3000 Single big size blade cutting machine or other GBHW series bridge saw machine together to cut different stone products, GBHW-1200 is automatic bridge saw machine, with high automatic lever. Clients can choose the model and size according to your processing size/production capacity requirements.



Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.


After-Sales Service

* Training how to install the machine, training how to use the machine.

* Engineers available to service machinery overseas.



FAQ

1. Do you have more stone machines?

Yes, we can produce all series of stone processing machines with competitive price and high quality.

2. Do you have agent?

We don't have agent as we all sell directly to our customer, in this way, the customer can get lowest cost.

3. How much is this machine?

Please tell me your stone is granite or marble, the size, your destination port, so that I can quote you best price.

4. How long can I get my product?

Normally it takes 30 days to produce our products.
